Pipe Clamp K-Type Thermocouple Probe - HI766TV1

In stock
The HI766TV1 is a roller surface K-type thermocouple probe with a handle designed for use with a thermocouple thermometer. A cable extends 1 m (3.3') from the handle to the thermocouple connector with the meter. The sensor that is housed inside the clamp allows users to obtain highly accurate temperature readings of pipes and tubes.
  • Measures up to 200°C (390°F)
  • 8 second response time
  • 35 mm clamp opening

The Pipe Clamp K-Type Thermocouple Probe - HI766TV1 is designed to measure the temperature of pipes and tubes that may be difficult to measure with traditional temperature probes. The response time of a measurement is affected by the position of the sensor relative to the surface being measured. The HI766TV1 clamp construction offers a speedy 8-second response for a temperature reading. With a 35 mm opening diameter of the pipe clamp, this probe is able to measure surfaces up to 200°C (390°F).


Recommended Operating Temperature 200°C (390°F)
Response Time (90% of final value) 4 seconds
Body Length Clamp opening max 35 mm (1.4")
Temperature Sensor yes
Cable polyurethane (PUR)/coiled; 1 m (3.3')
Recommended Use pipes, tubes
Connection K-Type
